Dual Telephone Line Surge Suppressor
ELK-955
The ELK-955 is a Two-Line RJ31X/38X Telephone Jack containing solid state transient suppression designed to protect the telephone inputs on an alarm control. It responds to power surges and transients in less than 1 nanosecond, automatically restoring after each surge within the specified ratings.
Product Details
- Superior Solid State Surge Suppression
- Rapid Response Time
- Protects Two Incoming Telephone Lines
- Clamps Line-To-Line & Line-To-Ground
- Self-restoring After Surges Within Ratings
- RJ31/38X 8-Pin Modular Jacks
- Convenient Test points for Lineman's Test set
- Surface Mount Enclosure
- Response Time: Less than 1 Nanosecond
- Breakover Voltage: 300 Volts
- Peak Pulse Current: 100 Amps
- Ground Wire: 24" - 14 Gauge Stranded
- FCC Reg. No. 5K6USA-23140-XP-N Ren No. 0.0B
- Size: 4.4" x 3" x 1.15"
The ELK-955 is compact and easy to install and features high quality, clearly labeled screw terminals, 8 pin modular phone connector, built-in tamper loop, and automatic shorting pins for cord removal. The ELK-955 is FCC Registered under part 68 and eliminates the need for a separate RJ31X telephone jack.
Resources
- ELK-955 Surge Suppressor
- Plastic Housing
- Instructions
